8
Microscopy Procedure
(Detailed)
4
★
Note that the figures in this manual show the “stage motion knobs” located on the right side and the
“condenser focus knob” located on the left side of the microscope body. These operating parts are
located on the opposite side depending on the model of the microscope. The “coarse focus knob” and
“coarse focus knob torque adjustment ring” are located on the opposite side of the “stage motion
knobs”. The “fine focus knob” is coaxial and located on both sides.
Preparation
Operations previous to the microscopy
1
Turn on the power switch.
Press the power switch to the “l” position and the
lamp will come on.
2
Lower the condenser slightly from its upper limit.
Turn the condenser focus knob to raise the
condenser to its upper limit once, and then lower it
slightly. (The condenser click-stops at its upper
limit.)
Power ON
Condenser focus knob
To Next Page
