Nikon ECLIPSE E200 MV Series - Chapter 10 Specifications; Microscopy (Principles); Performance Properties

45
Specifications
10
1
Microscopy (Principles)
Use the objective and eyepieces of the microscope to magnify minute cells and tissue optically,
manipulate the lever and handle of the microscope unit to precisely focus or move the
observation point. Then observe or shoot the sample fixed on the slide.
• Intended application of the product (for medical care)
This microscope is designed for the purpose of experimentations and diagnosis in
microscopic observation of cells and tissue at hospitals or independent medical clinics, etc.
and practices at educational institutes in the field of medicine, anatomy, and cellular biology.
The bright field diascopic (transmitted) observation is used to observe a sample fixed on the
slide (cells and tissue) as the specimen.
The product is classified as an in-vitro diagnostic medical device.
This product is not intended for use for measurement.
The scale on the focus handle and stage is an indicator to reproduce the position and does
not guarantee the value of the thickness or length of a sample measured using this scale.
• Intended user
It is intended for the medical professional and those who work on experimentations and
practitioners of the microscope observation at educational institutes in the field of medicine,
anatomy, and cellular biology.
2
Performance Properties
(1) Model Name: Microscope Main Body
• E200 MV Series
ECLIPSE E200 MV L (Stage knob left side, without field diaphragm)
ECLIPSE E200 MV LS (Stage knob left side, with field diaphragm)
ECLIPSE E200 MV R (Stage knob right side, without field diaphragm)
ECLIPSE E200 MV RS (Stage knob right side, with field diaphragm)
• E200LED MV Series
ECLIPSE E200LED MV L (Stage knob left side, without field diaphragm)
ECLIPSE E200LED MV LS (Stage knob left side, with field diaphragm)
ECLIPSE E200LED MV R (Stage knob right side, without field
diaphragm)
ECLIPSE E200LED MV RS (Stage knob right side, with field
diaphragm)
Eyepiece Tube
E2-TB (Binocular eyepiece tube)
E2-TF (Trinocular eyepiece tube)
(2) Optical System: CFI60 (Infinity-corrected CF optical system)
Second objective focal length f = 200 mm
Built-in diascopic illumination system (Simplified Kohler’s illumination system)
(3) Focusing
Mechanism:
Fine focus knob graduation: 2μm/graduation
Fine focus knob travel: 0.2 mm up or down / revolution
Coarse focus knob travel: about 37.7 mm up or down / revolution
Stage vertical movable range: 1.5 mm upward and 25 mm downward
from the focal plane.
