Contents
ii
Contents
Introduction ................................................................................................. i
Safety Precautions ..................................................................................... iv
WARNING and CAUTION Symbols Used in This Manual ...............................iv
Symbols on the Product..........................................................................v
WARNING .......................................................................................vi
CAUTION ...................................................................................... viii
Notes on Handling the Product................................................................... ix
Chapter 1
Nomenclature of Each Part....................................................... 2
Chapter 2 Switches and Controls.............................................................. 4
Chapter 3 Microscopy Procedure (Quick Reference)................................. 6
Chapter 4 Microscopy Procedure (Detailed) ............................................. 8
Preparation Operations previous to the microscopy ...................................... 8
1 Turn on the power switch. ............................................................ 8
2 Lower the condenser slightly from its upper limit. ............................ 8
3 Fully open the field aperture and condenser aperture diaphragms.
(Field diaphragm control is only for microscopes
with the field diaphragm.) ............................................................ 9
4 Bring the 10x objective into the optical path. .................................. 9
5 Place the specimen slide on the stage and bring the specimen
into the optical path. ..................................................................10
6 Focus on the specimen. ..............................................................10
7 Adjust the diopter ring on the eyepieces........................................12
8 Adjust the interpupillary distance. ................................................13
9 Focus on the field diaphragm and center its position.
(This adjustment is only for microscopes with the field diaphragm.) ..14
Microscopy Operations for actual microscopy............................................15
10 Select the objective....................................................................15
11 Adjust the condenser aperture diaphragm. ....................................15
12 Focus on the specimen. ..............................................................17
13 Adjust the field diaphragm.
(This adjustment is only for microscopes with the field diaphragm.) ..18
14 Perform the microscopy. .............................................................18
15 Turn off the power switch............................................................21
