Nikon ECLIPSE E200 MV Series - Page 17

Chapter 2 Switches and Controls
5
2
(1) Diopter ring
(2) Revolving
nosepiece
(3) Stage
(4) Specimen holder
(5) Condenser aperture
diaphragm lever
(7) Condenser auxiliary lens
(6) Condenser clamp
screw
(16) Condenser focus knob
(19) Coarse focus knob torque
adjustment ring
(20) Nameplate
(17) Fine focus knob
(21) AC inlet
(13) Fine focus knob
(10) Lateral stage motion
(X Axis) knob
(9) Longitudinal stage
motion (Y Axis) knob
(15) Brightness control dial
(14) Power switch
(12) Field diaphragm
centering screws
(11) Field diaphragm ring
(8) Filter holder
(18) Coarse focus Knob
