Lamp Illumination
1
Turn on the power switch (turn to |) and the lamp
will come on. Turn the brightness control dial to
adjust the brightness of the viewfield. (Turning the
dial clockwise increases the brightness; turning the
dial counterclockwise decreases it.)
Interpupillary Distance Adjustment
2
Adjust the distance between the eyepieces to
merge the right and left viewfields into one. (This is
an adjustment to match the distance between
eyepieces with the distance between your eyes).
Align the Diopter Ring with the Engraved Base Line
3
Turn the diopter ring on the right eyepiece to align
its bottom edge with the engraved base line. Turn
and align the diopter ring on the left eyepiece in
the same way.
4
Specimen Mounting
Place specimen slide on the stage with the coverglass facing upward and fix with the specimen
clips.
Power ON
Bri
To Next Page
