IV Microscopy (Detailed Procedure)
16
Focus with the 10x Objective
5
Rotate the revolving nosepiece to bring the 10x
objective into the optical path. (The objective will
click into place when rotated into position.)
Bring the specimen image into focus by turning the
coarse focus and then fine focus knob.
• Direction of stage movement relative to focus
knob rotation is shown in the figure.
• There is no coarse focus knob on the opposite
side of condenser focus knobs.
• Do not turn the right and left focus knobs
simultaneously in the opposite directions. Do not
turn the coarse focus knob further after the stage
has reached its lower or upper limit. These
operations could result in a malfunction.
Click.
