Chapter 3 Operation
3.14 PFS (Perfect Focus System) Operation
83
Supported objectives
The following objectives can be used for in-focus observation with the PFS. Use of other objectives will result
in an error, and “PFS: ER1” will be displayed on the status display panel.
Table: PFS ready objectives
Model name NA
WD
(mm)
Type Model name NA
WD
(mm)
Type
Apo TIRF 60xH 1.49 0.12 Oil Plan Fluor 10x 0.3 16 Dry
Apo TIRF 100xH 1.49 0.12 Oil Plan Fluor DLL 10x 0.3 16 Dry
Plan Apo 4x 0.2 15.7 Dry Plan Fluor ELWD 20xC 0.45 7.4 Dry
Plan Apo 10x 0.45 4 Dry Plan Fluor ELWD ADL 20xC 0.45 7.4 Dry
Plan Apo 20x 0.75 1 Dry Plan Fluor ELWD DM 20xC 0.45 7.4 Dry
Plan Apo 40x 0.95 0.14 Dry Plan Fluor 40x 0.75 0.72 Dry
Plan Apo DM 40x 0.95 0.14 Dry Plan Fluor 40xH 1.3 0.2 Oil
Plan Apo 60xHA 1.4 0.21 Oil Plan Fluor DLL 40x 0.75 0.72 Dry
Plan Apo 60xWI 1.2 0.22 WI Plan Fluor ELWD 40xC 0.6 3.7-2.7 Dry
Plan Apo DM 60xHA 1.4 0.21 Oil Plan Fluor ELWD ADL 40xC 0.6 3.7-2.7 Dry
Plan Apo DM 60xH 1.4 0.21 Oil Plan Fluor ELWD DM 40xC 0.6 3.7-2.7 Dry
Plan Apo 100xH 1.4 0.13 Oil Plan Fluor 100x H 1.3 0.2 Oil
Plan Apo DM 100xH 1.4 0.13 Oil Plan Fluor ADH 100x H 1.3 0.19 Oil
Plan Apo TIRF 60xH 1.45 0.13 Oil Plan Fluor DLL 100x H 1.3 0.2 Oil
Plan Apo TIRF 100xH 1.45 0.13 Oil S Fluor 4x 0.2 15.5 Dry
Plan Apo VC 60xWI 1.2 0.27 WI S Fluor 10x 0.5 1.2 Dry
Plan Apo VC 60xH 1.4 0.13 Oil S Fluor 20x 0.75 1.00 Dry
Plan Apo VC 100xH 1.4 0.13 Oil S Fluor DL 20x 0.75 1.00 Dry
S Fluor 40xH 1.3 0.22 Oil
S Fluor DL 40xC 0.9 0.3 Dry
S Plan Fluor ELWD 20xC 0.45 8.2-6.9 Dry
S Plan Fluor ELWD ADM 20xC 0.45 8.2-6.9 Dry
S Plan Fluor ELWD 40xC 0.6 3.6-2.8 Dry
S Plan Fluor ELWD ADM 40xC 0.6 3.6-2.8 Dry
To perform the PFS function, you will need to register the objective information on the microscope.
For registration details, refer to Chapter 4, “Assembly.”
