Show data
You can read off current operating data for the unit. This will help you ensure that the unit is operating satisfactorily. It can also help
you identify the cause of potential alarms.
> Show data
> Status Description: Shows the operating setting in which the unit is running:
Off: Heat pump stopped.
HP stop: The heat pump has stopped due to an alarm.
Wait: Compressor is still prevented from starting up. The stop-
ping-time has not passed.
Ready: The stopping-time has passed and the compressor is
ready for start-up.
Start-up: Start-up heat pump.
Hot water: Heating of domestic hot water by either a heat pump
or supplemental electric heating.
Heating: Central heating heated by either a heat pump or sup-
plemental electric heating.
> Operation mode Description: Shows whether the user has selected ‘Winter’ or ‘Summer’ mode
manually in Operation mode, or which type of operation AUTO
has selected automatically.
> Anode Description: Shows whether the anode is in working order. Display: Off, OK,
Error or Service. In the case of Error or Service, please contact a
technician.
> T16 Return heating Description: Shows the current temperature of the return flow from the
indoor unit to the outdoor unit.
> T17 Supply heating Description: Shows the current temperature of the supply flow from the
outdoor unit to the indoor unit.
> T18 Buffer tank Description: Shows the current temperature of the supply flow to the buffer
tank.
> T20 Outdoor temperature Description: Shows the outdoor temperature measured in the outdoor unit.
> T21 Top temperature Description: Shows the current temperature at the top of the DHW tank.
Controls the supplemental electric heating.
> T22 Bottom temperature Description: Shows the current temperature at the bottom of the DHW tank.
Controls the heat pump.
> T23 Evaporator temperature Description: Shows the current evaporator temperature.
> T35 Pressure pipe tempera-
ture
Description: Shows the temperature in the pressure pipe.
> Water setpoint Description: Currently used setpoint for domestic water. The setpoint you
select can be staggered by a week program or Smart Grid.
> Heating setpoint Description: Currently used setpoint for central heating. You can select the
setpoint manually or it can be selected automatically by the
weather compensation. It may be staggered by a week program
or Smart Grid.
> Actual capacity Description: Shows the capacity of the compressor in %
> Inverter Description: Shows the current control voltage to the inverter/compressor
> Fan power Description: Shows the current control voltage to the fan by the evaporator
> Unit information Description: Shows information about the unit in the submenus
> AIR SW. version Description: Current AIR controller software version
> Panel software Description: Current panel/HMI350T software version
