nilan CTS602 HMI User Manual

16
Central heating
Here, weather compensation is used to regulate the supply flow temperature of the central heating in order to optimize operation of
the unit.
> Weather compensation / Curve for outdoor temperature
> Curve for outdoor temperature Settings:
Default setting:
Description:
De-activated / Manual / Curve 1 / Curve 2 / Curve 3 / Curve 4 /
Curve 5 / Curve 6 / Curve 7 / Curve 8 / Curve 9 / Curve 10
Deactivated
De-activated: The unit is regulated in accordance with a fixed
supply flow temperature.
Manual: Here you can define the curve yourself. When switch-
ing from a fixed curve to a manual curve, the basis will initially
be the last fixed curve that was used.
> Manual
> Min. setpoint Settings:
Default setting:
Description:
10  55 ºC
20 ºC
This is where you set the minimum supply flow temperature.
>Offset Settings:
Default setting:
Description:
-10  10 ºC
0 ºC
Offset in relation to the selected curve
> Setpoint at act.amb.temp. Description: The temperature here is a readout of the setpoint of the
weather compensation at current outdoor temperatures and
settings for curve selection, offset, min. and max. settings.
> Curve point -20°C Settings:
Default setting:
10 - 100 °C
50°C
> Curve point -10°C Settings:
Default setting:
10 - 90 °C
47°C
> Curve point 0°C Settings:
Default setting:
10 - 70 °C
40°C
> Curve point 10°C Settings:
Default setting:
10 - 55 °C
31°C
> Curve point 20°C Settings:
Default setting:
10 - 55 °C
20°C
> Curve point 30°C Settings:
Default setting:
10 - 55 °C
20°C
> Curve point 40°C Settings:
Default setting:
10 - 55 °C
20°C
> Curve 1-10
> Min. setpoint Settings:
Default setting:
Description:
10  55 ºC
20 ºC
This is where you set the minimum supply flow temperature.
>Offset Settings:
Default setting:
Description:
-10  10 ºC
0 ºC
Offset in relation to the selected curve
> Setpoint at act.amb.temp. Description: The temperature here is a readout of the setpoint of the
weather compensation at current outdoor temperatures and
settings for curve selection, offset, min. and max. settings.
