Installation
Positioning the unit
ATTENTION
Good clearance in front of the unit is recommended (see table below). When positioning the unit, you should
always consider future service and maintenance. It must be easy to replace fi lters and it must be possible to
replace fans or other components. There must be enough space to clean the unit easily. There must be space for
installing water traps in the condensate drains.
ATTENTION
The unit must be level to enable proper drainage from the condensate tray.
ATTENTION
The unit makes little noise and it produces only weak vibrations, but you should still take into account potential
vibrations that can spread from the unit to individual building components. In order to separate the unit from its
underlying surface, it is therefore recommended that you fi t vibration absorbers under the unit. There should
be approx. 10 mm distance to other building components and to permanent fi xtures.
X
Unit X (in mm)
VPM 600 750
VPM 700 750
VPM 800 750
VPM 1000 750
VPM 1200 800
VPM 1500 800
VPM 2200 950
VPM 3200 1050
