nilan CTS602I HMI User Manual

28
Electrical connection accessories
Electrical after-heating element
Electrical after-heating element
WARNING
The electrical after-heating element must be connected up by a certifi ed electrician.
WARNING
The power supply cable must be connected up via a maintenance switch (accessory).
ATTENTION
The communication cable should be mounted on the circuit board in accordance with the wiring diagram.
If you have ordered an electrical after-heating element as an accessory, a heating element type EB for the VPM/VPR 600-3200
series will be factory installed.
The following heating elements EB 14-120 kW are suitable for the VPM/VPR-series:
Ventilation unit EB14 EB21 EB28 EB35 EB42 EB49 EB63 EB74 EB84 EB120
VPM/VPR 600 X X X X X
VPM/VPR 700 X X X X X X
VPM/VPR 800 X X X X X X
VPM/VPR 1000 X X X X X X
VPM/VPR 1200 X X X X X X X X
VPM/VPR 1500 X X X X X X X X X
VPM/VPR 2200 X X X X X X X X
VPM/VPR 3200 X X X X X X
