VPM/VPR 3200
VPM/VPR3200
The heating element has two rows of pipes and a 5/4” RG connection.
Control valve (accessory): Select when ordering.
Flow-/return
temperature
Air volume
m
3
/h
Supply air temp.
°C
Output
kW
Pressure drop
(water)
kPa
Pressure drop
(air)
Pa
Water volume
l/h
70/40
11,000 37.2 102 2.7 10.0 815
18,000 32.1 136 4.6 21.9 1087
25,000 29.1 162 6.4 36.8 1300
32,000 26.9 185 8.0 54.5 1478
60/30
11,000 29.4 73 1.5 9.9 583
18,000 25.8 97 2.5 21.6 777
25,000 23.6 116 3.5 36.5 928
32,000 22.0 132 4.4 54.1 1052
50/30
11,000 27.5 66 2.6 9.9 790
18,000 24.3 88 4.5 21.5 1055
25,000 22.3 105 6.2 36.4 1263
32,000 21.0 120 7.9 54.0 1460
