Nilfisk-Advance SC6000 36C User Manual

111Service Manual – SC6000 34 - Scrub System, Cylindrical
8. Remove the lower retaining clip and pin (F) from the
actuator.
9. Taking care to not rotate the leadnut with respect to the
actuator body, lift the actuator out from above. You may
need to rotate the whole assembly clockwise slightly to
clear the motor-side of the actuator from the battery bay
panel.
10. As necessary, perform the Lift Actuator Limit
Adjustment described on page 106.
F

Nilfisk-Advance SC6000 36C Specifications

General

Brand	Nilfisk-Advance
Model	SC6000 36C
Category	Scrubber
Language	English
