Nilfisk-Advance SC900-28D User Manual

10Service Manual – SC900 03 - General Information
Technical Specications
Model SC900 28D SC900 34D SC900 32C
Model No. 56115201 56115202 56115203
Voltage, Batteries 36V (6 x 6V)
Battery Capacity 310 Ah
Protection Grade na
S P L IEC 60335-2-72: 2002 Amend. 1:2005,
ISO 11201
66.4 dB(A)/20µPa 66.4 dB(A)/20µPa 68.8 dB(A)/20µPa
S P L – KpA (IEC 60335-2-72, ISO 11201)
Uncertainty
< 70 dB(A)
Vibrations at the Hand Controls (ISO 5349-1) 0.510 m/s
2
0.381 m/s
2
0.476 m/s
2
Vibrations at the Hand Controls (ISO 5349-1)
Uncertainty
< 2.5 m/s
2
Maximum Wheel Floor Loading (right front) 147 psi / 1.0 N/mm
2
128 psi / 0.89 N/mm
2
155 psi / 1.1 N/mm
2
Maximum Wheel Floor Loading (left front) 107 psi / 0.74 N/mm
2
132 psi / 1.0 N/mm
2
128 psi / 0.88 N/mm
2
Maximum Wheel Floor Loading (right rear) 205 psi / 1.4 N/mm
2
432 psi / 3.0 N/mm
2
245 psi / 1.7 N/mm
2
Maximum Wheel Floor Loading (left rear) 521 psi / 5.6 N/mm
2
640 psi / 4.4 N/mm
2
416 psi / 2.9 N/mm
2
Machine Width (chasis) 30.3” / 77.0 cm 30.3” / 77.0 cm 30.6” / 77.7 cm
Machine Width with Squeegee 41.8” / 106.2 cm 41.8” / 106.2 cm 41.8” / 106.2 cm
Machine Height 44.8” / 113.8 cm
MachineLength 65.4” / 166 cm 67.4” / 171 cm 63.1” / 160.3 cm
Solution Tank Capacity 29.5 Gal / 111.7 L
Recovery Tank Capacity 32 Gal / 121 L
Battery Compartment Size (approximate) Height (maximum)
Width (maximum)
Length (maximum)
15 in / 38 cm
26 in / 66 cm
27.5 in / 70 cm
Scrub brush size (2 per machine)
Ø 14 inch / 35.5 cm Ø 17 inch / 43.1 cm
5.5 x 31 Inch
13.9 x 78.7 cm
Scrub Brush Speed ( Left / Right ) 255 / 259 RPM 256 / 260 RPM 820 / 735 RPM
Cleaning Path Width (scrubbing path) 28 inch / 71.1 cm 34 inch / 86.3 cm 31 inch / 78.7 cm
Gross Weight* 1189 Lbs. 539,3kg 1205 Lbs. 546,8kg 1235 Lbs. 560,2kg
Transport Weight** 942 lbs / 427 kg 979 lbs / 444 kg 1006 lbs / 456 kg
Vacuum Motor Size 710 watts max HP 0.95
Drive Motor Size .5 HP
Brush Motor Size 0.75 HP
Maximum Scrub Speed 3.2
Maximum Transport Speed 3.2
Gradeability Transport 16% (9.1°)
Gradeability Cleaning 8.3% (4.75°)
*Gross Weight: Standard machine without options, full solution tank and empty recovery tank, with removable
scrub brushes and 310 AH batteries installed.
**Transportation Weight: Standard machine without options, empty solution and recovery tanks, with batteries
installed and no operator.

Nilfisk-Advance SC900-28D Specifications

General

Brand	Nilfisk-Advance
Model	SC900-28D
Category	Floor Machine
Language	English
