INSTRUCTIONS FOR USE ENGLISH
1464815000 - SW4000, FLOORTEC R 870 11
03/2013
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specic use:
– Left side broom
– Main and side brooms with harder or softer bristles
– Paper dust lter (standard for FLOORTEC R 870)
– Non-marking skirts
– Working lights
– Safety belts
– Right and left armrests
– Non-marking wheels
– FOPS protective roof
– Roof cover
– Side broom guards
– DustGuard™ system
For further information concerning the optional accessories, contact an authorised Retailer.
TECHNICAL DATA
Model SW4000 P
FLOORTEC R 870 P
SW4000 LP
FLOORTEC R 870 LP
Cleaning width with one side broom 975 mm
with two side brooms 1,250 mm
Main broom size (length x diameter) 700 x 340 mm
Side broom diameter 450 mm
Theoretical working capacity main broom 4,900 m
2
/h
with one side broom 6,825 m
2
/h
with two side brooms 8,750 m
2
/h
Hopper capacity 75 litres
maximum liftable weight 100 kg
maximum lifting height 1,590 mm
Filter cleaning system Electrical lter shaker
area 7 m
2
ltering capacity 4 µm
Power 4.1 kW (5.5 hp) @ 3,600 rpm
Engine model Honda GX-200
Fuel tank capacity 7.8 litres 15 Kg
Main broom motor power 600 W
speed 550 rpm
Side broom motor power 90 W
speed 110 rpm
Vacuum motor power 260 W
Drive type Electric drive on front wheel
gearmotor power 1,000 W
forward speed 7 km/h
reverse speed 4.5 km/h
Maximum gradient when working 20 %
Hopper hydraulic control unit 250 W
Filter shaker motor 90 W
Total absorbed power 2.0 kW
Working autonomy 13 h 25 h
Dimensions
(length x width x height)
machine body 1,640 x 1,035 x 1,330 mm
machine with side brooms 1,640 x 1,050 x 1,330 mm
machine with ashing light 1,640 x 1,035 x 1,390 mm
machine with FOPS protective roof (optional) 1,640 x 1,035 x 1,990 mm
battery compartment 360 x 380 x 220 mm
LPG tank maximum size (length x diameter) - 720 x 300 mm
Revised 02/2017
