ENGLISH QUICK START GUIDE
40 SW4000 - 1464813000
NOTE
,IQHFHVVDU\PDQXDOO\HQJDJHWKHKRSSHULQSRVLWLRQ$ZLWKWKHUHWXUQLQJKDQGOH(ZKHQWKHKRLVWLQJV\VWHPLVOLIWHG
DQGWKHKRSSHULVGLVHQJDJHG%
CAUTION!
The hopper (A) can be dumped only when lifted at a minimum height of 35 cm approximately.
The maximum dumping height is approx. 150 cm.
5. Lower the hopper by pressing both the enabling switch (66) and the switch (79).
NOTE
7RHQVXUHWKDWWKHKRSSHULVIXOO\UHWUDFWHGFKHFNWKDWWKHZDUQLQJOLJKWLVRII
6. The machine is ready to start sweeping and vacuuming again.
max
100 Kg
(220 lb)
A
D
C E
B
1500 mm
(59 in)
P100592
Figure 1
AFTER USING THE MACHINE
After working, before leaving the machine, perform the following procedures.
– 7XUQRQWKH¿OWHUVKDNHUVKRUWO\E\SUHVVLQJWKHORZHUSDUWRIWKHVZLWFK
– Empty the hopper (11) (see the procedure in the previous paragraph).
– Lift the main broom with the lever (63).
– Lift the side brooms with the lever (64).
– (For LPG version). Close the safety valve on the LPG tank (56), then let the engine run until all the fuel is expelled from the
hoses (then the engine is stopped).
– Turn off the machine by turning the ignition key (61) to “0”, then remove it.
– Engage the parking brake.
MACHINE LONG INACTIVITY
If the machine is not going to be used for more than 30 days, proceed as follows:
– Check that the machine storage area is dry and clean.
– (For Petrol version). Close the fuel tap (34).
– (For LPG version). Close the LPG tank safety valve.
– Disconnect the negative connector (-) of the batteries (46).
– Handle the engine (42) as shown in the relevant Manual.
– )RUPDFKLQHVHTXLSSHGZLWKGXVWJXDUGV\VWHP(PSW\WKHWDQNDQGFOHDQWKHZDWHU¿OWHUVHHWKHSURFHGXUHLQ
Maintenance chapter in the User Manual).
FIRST PERIOD OF USE
$IWHUWKH¿UVWKRXUVSHUIRUPWKHIROORZLQJSURFHGXUHV
– Change the engine oil (see the procedure in Maintenance chapter in the User Manual).
