MACHINE STRUCTURE (Continues)
41. Battery compartment hood opening handle
42. Lead batteries (WET) or optional gel batteries (GEL-AGM)
43. Battery caps (for WET batteries only)
44. Battery connection diagram
45. Battery connector
46. Right side broom motor resettable thermal fuse
47. Left side broom motor resettable thermal fuse (optional)
48. /DPHOODUIXVHER[
49. (OHFWULFDOFRPSRQHQWER[
50. Drive system electronic board
51. Hydraulic unit with tank for hopper lifting
52. Open hood safety rod
53. Vacuum system motor connector
41
52
42
43
51
45
50
48
49
53
47
46
BATTERY
PLUG
44
6V
6V
6V
6V
BATTERY
PLUG
24V
P100589
