OPERATOR’S MANUAL FOR INFANT INCUBATOR EDITION/REVISION B/0
10. Keypad lock indicator
If this light is on, it means entering into the set state and all functional keys active; if the light
is off, it means the system is not in set state, and all keys are locked.
（NOTE: Except for the Oxygen Concentration Indicator key, Humidity Indicator key, Zero
key, Calibration key and Switch Setting Indicator key.）
11. Heater power indicator
Indicate the heater output proportion.
12. Baby mode indication light
This light is on when it is in Baby Mode.
13. Battery condition indication light
It will show the condition of the electricity, and the yellow light means it is charging, while the
green one means it is full. The temperature control will check the condition of the battery during
incubator working and charge and discharge automatically.
14. ＞37 indicator℃
This light is on means the incubator is working under the state of ＞37 , and the patient is ℃
in the environment of high temperature.
15. Skin temperature indicator
Display the baby temperature detected by skin temperature sensor 1, press Baby Mode key
and Set Up key, it display the baby temperature detected by skin temperature sensor 2.
16. Message indicator
When the device normally working, it displaying the current time. When the device is
alarming, it displaying the alarm information.
17. System alarming indicator light
It shines when incubator inner system failure.
Please stop operating immediately and repairing by qulified personnel once this
light shines.
18. Zero key
Press this key to reset the weight display on the indicator，the reset range is 0~2000g.
19. Calibration key
This key is used only for calibrate the weigh sensor，do not press in the normal operation.
20. Weight indicator
Display the weight tested by weighing sytem
21. Oxygen supplement indicating light
When the light of this indicator enlightened, the oxygen supplement system is on working.
