Warning
Be careful not to mount a gripper that is not supplied by Niryo. If you would like to design
your own gripping tool, contact our Support Service;
Never use loads greater than those stated in the robot specications (chapter 9) as this could
cause mechanical crushing should the object or the gripper fall. Such improper use could also
damage the robot;
Make sure that the tool is mounted correctly by following the assembly instructions above;
Be careful not to put your fingers between the jaws of the gripper.
Vision Set mountingVision Set mounting
To mount the Vision Set, all you need to do is attach the camera to Ned2’s wrist. The cable of the vision set
need to pass through the wrist to avoid trouble during movement of the robot. You can set up and x your
workspace to Ned2’s structure to have a stable environment.
Electrical interfaceElectrical interface
Electrical interface overviewElectrical interface overview
Electrical architecture
