Niryo Ned2 - Back Panel Interface

Back Panel interfaceBack Panel interface
Ned2 comes with I/O interface that can be used for wide range of equipements and Ned2 ecosystem.
The illustration below shows the dierents electrical and communication interfaces present of the back
panel of the robot.
Connector table
1 2 x USB 2.0
2 2 x USB 3.0
3 RJ45 port
4 Wi-Fi status indicator
5 Wi-Fi button
6
3 x digital inputs
7 3 x digital outputs
