BKI16ATEX0018X ♦ htk4014a0600p_03 ♦ 55 / 76
Function (Fct.) Input Range Description
2.1.3.0 ANALOG OUTPUT
Select Level, Distance, Volume, Ullage
Volume
2.1.3.1 FUNCTION I
Level
Current output function (measured value to be displayed). Volume functions
will appear if a volume table exists in menu 2.1.7.0
Select 4-20 mA or 4-20 mA + 22 mA if error 2.1.3.2 RANGE I
4 - 20 mA
Current output range 4 … 20 mA
(1
st
choice). When the MicroTREK 2-wire is in error mode, the current
output is frozen except if the second choice is selected and then the current
output is fixed at 22 mA.
Select No delay, 10 s, 20 s, 30 s, 1 min, 2
min, 5 min, 15 min
2.1.3.3 ERROR DELAY
No delay
This menu is available in case
the range I menu is set to 4-20 mA with error 22 mA.
This parameter sets the delay before the current output goes to 22 mA after
the error mode occurred.
Enter 0 to Scale I max 2.1.3.4 SCALE I
min. 4 mA
As per order
Input the lower range value (corresponding to 4 mA) depending of the
parameter 2.1.3.1 chosen.
Enter Scale I min to tank height 2.1.3.5 SCALE I
max. 20 mA
As per order
Input the upper range value (corresponding to 20 mA) depending of the
parameter 2.1.3.1 chosen.
