FIGURE A.2.1.2（B）Centrifugal Fire Pumps Split-Case Type Group Lifting
2.1.3 Diesel Engine Fire Pump Group Lifting
1. The lifting ring on the top of the diesel engine can only be used to lift the engine, not the
whole group equipment.
2. Attention should be paid to the direction of tension when lifting the pump group. If the
direction of tension at both ends exceeds 90 degrees, it is not allowed.
FIGURE A.2.1.3 Diesel Engine Fire Pump Group Lifting
3.0 INSTALLATION
This task is undertaken only by properly trained and experienced service personnel.
