Noble UL30 - Terminal Block Box Assembly

25
1
2
3
4
5
6
7
8
9
ITEM QTY DESCRIPTION PART NUMBER
1 1 Decal. Power Connections 09905-011-47-35
2 1 Terminal Block Box 05700-003-27-69
1 Terminal Box Cover (not shown) 05700-003-27-70
3 1 Decal, Copper Conductors 09905-001-62-72
4 1 Screw, 1--32 X 1/2” 05305-011-39-36
5 1 Ground Lug 05940-200-76-00
6 1 Screw, 1--32 X 1/2” 05305-011-39-36
7 2 (3 per 480V) Terminal Block 05940-500-02-19
8 1 Locknut, 10-24 S/S Hex w/ Nylon Insert 05310-373-01-00
9 1 Terminal Block Track 05700-000-43-60
PARTS
TERMINAL BLOCK BOX ASSEMBLY
