Noble UL30 - Chemical Feeder Pump Components

30
CHEMICAL FEEDER PUMP COMPONENTS
PARTS
1
2
3
4
5
6
8
7
ITEM QTY DESCRIPTION PART NUMBER
1 1 Rear Housing 04320-111-37-09
2 2 Screw, 8-32 X 3/8” Phillips Pan Head 05305-011-37-07
3 4 Screw, 6-32 X 32 X 3/4” Phillips Pan Head 05305-011-37-05
4 1 Front Housing 04320-111-37-08
5 1 Roller, Black 04320-111-65-27
1 Roller, White 04320-002-82-28
6 1 Tygoprene Tube 05700-03-22-89
7 2 Screw, 8-32 X 1/2” Phillips Flat Head 05305-011-37-06
8 1 Motor, 14 RPM 115V Rinse Aid Feeder Pump 04320-111-35-13
Motor, 14 RPM 240V Rinse Aid Feeder Pump 04320-111-47-46
Motor, 36 RPM 115V Detergent/Sanitizer Feeder Pump 04320-111-35-14
Motor, 36 RPM 240V Detergent/Sanitizer Feeder Pump 04320-111-47-47
