44
CLYDE SWITCH ARM
PARTS
1
4
6
5
3
2
ITEM QTY DESCRIPTION PART NUMBER
Clyde Switch Arm Assembly 05700-003-52-14
1 1 F-Plate, Switch Cover RT 05700-003-52-10
2 1 Screw, 6-32 X 5/8” 05305-011-39-85
3 1 Lock Nut 6-32 Hex w/ Nylon Insert 05310-373-03-00
4 1 Cycle Switch Weldment 05700-003-36-81
5 2 Term, 190030013 .187 Pink Reel 05940-111-45-18
6 1 Wire Nut, Blue Metal 30-172 Ideal 05945-111-01-00
To Next Page
