Noble UL30 - Uh30 Thermostat & Rinse Tank Assembly

40
ITEM QTY DESCRIPTION PART NUMBER
1 1 Rinse Tank Weldment 05700-003-31-95
2 1 Fittin, 1/4” Imperial Brass 05310-924-02-05
3 1
Heater: 208-230 Volt
Heater: 480 Volt
04540-111-43-21
04540-002-29-82
4 4 Lock Washer, 5/16” Split 05311-275-01-00
5 4 Nut, Hex 5/16”- 18 S/S Hex 05310-275-01-00
6 1 Gasket, Heater 05330-011-47-79
7 9 Locknut, 1/4”-20 S/S Hex w/ Nylon Insert` 05310-374-01-00
8 1 Dielectric Cover 05700-001-40-50
9 1 Thermostat 05930-003-06-48
UH30 THERMOSTAT & RINSE TANK ASSEMBLY
PARTS
7
6
5
4
3
2
1
9
8
