Noble UL30 - Page 46

41
NOBLE UL30 OPTIONAL
THERMOSTAT & HEATER COMPONENTS
PARTS
1
2
3
4
5
ITEM QTY DESCRIPTION PART NUMBER
1 1 Wash Thermostat 05930-003-13-65
2 1 Heater, Fire Bar 04540-003-46-27
3 1 Insulation Paper 1/8” 04540-003-46-30
4 1 Heater Cover Plate 05700-003-46-37
5 1 High Limit Thermostat 06685-003-46-77
