32
UH30 PLUMBING ASSEMBLIES
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 1/2 “ Plumbing Section 05700-003-32-17
2 1 A-Plumbing, Inlet Booter 05700-003-33-97
3 1 A-Plumbing, Inlet Vavle-Booster 05700-003-33-98
4 1 A-Plumbing, Inlet Hook-Up 05700-003-33-99
5 1 A-Injector, Incoming Assembly 05700-003-22-01
6 1 Assy, Noble UH30 Vaccum Break 05700-003-32-15
7 1 Vac BRKR 1/2 Brass Bon.EDP-0336402 04820-003-06-13
8 1 Nipple-1/2 Close Brass 04730-207-15-00
9 2 Clamp, Pipe 05700-000-35-05
10 1 Clamp, Pipe 05700-011-38-62
11 2 Lock Nut 1/4-20 S/S 05310-374-01-00
12 2 Rinse Hub Weldment 05700-021-38-31
13 2 Rinse Gasket 05330-111-42-81
ITEM QTY DESCRIPTION PART NUMBER
1 1 W-Weld, Injector Machined 05700-031-41-83
2 2 Plug, 1/4 211 P-4 Brass 04730-209-01-00
3 1 Valve, Check 04820-111-51-14
4 1 Ftg, Outlet Elbow (ECO9218-8044) 04820-111-51-18
5 1 Nut, Tube 1/8PP Jaco P-0-2-SPEC Ecolab #92008002 04730-011-59-45
6 1 Bushing, 1/4 X 1/8 Stainless 04730-003-05-61
NOTE:
USE TEFLON TAPE ON THREADS, DO NOT USE PIPE DOPE
A-INJECTOR, INCOMING ASSEMBLY
PLUMBING ASSEMBLIES
