36
NOBLE UL30 WASH MANIFOLD ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Hub, Discharge Machine (Noble UH30 Shown) 05700-021-37-90
1A 1 Lower, Wash Manifold (Noble UL30) 05700-021-52-80
2 1 Gasket, Manifold 05330-200-23-00
3 1 Nut, Jam 1-1/2” -12 NPT 05700-000-86-23
4 4 Hose Clamp, 1-5/16”-2 1/4” #28 04730-719-01-37
5 Hose, 1-1/4” X 2-1/4” Reinforced 05700-011-44-48
6 1 Hose, Bottom Manifold Pump 05700-001-22-92
7 Gasket, Suction Adaptor 05330-003-32-82
8 1
2
3
Casting, Suction Adaptor
Washer, S/S 1/4”-20 I.D.
Locknut, 1/4”-20 S/S
09515-031-39-86
05311-174-01-00
05310-374-01-00
9 Clamp, 3/16” to 1-1/2” 04730-719-06-09
10 Hose, 8” Straight Drain 04720-003-27-95
11 Hosebarb, 1”X 3/4” NPT Polypropylene 04730-011-65-86
12 Spacer, Drain Valve 05700-003-31-93
13 Bracket, Drain Vavle Support 05700-003-31-74
14 Hose, 1” I.D. X Ten Feet Long 05700-011-39-72
15 Hosebarb, 90 Degree 1” X 3/4” NPT 04730-011-65-87
16 O-Ring, Manifold 05330-111-35-15
17 Tube, Wash Manifold 05700-002-13-75
18 Upper Wash Manifold 05700-031-34-82
19
Bracket, Manifold Tube Positioning
Locknut 1/4”-20 S/S
05700-011-34-63
05310-374-01-00
WASH MOTOR/DRAIN PLUMBING/NOBLE UL30 WASH MANIFOLD ASSEMBLY
