46
MISCELLANEOUS DOOR COMPONENTS
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Switch Mounting Plate Assembly 05700-003-33-54
2 1 Door Spring 05700-003-32-85
3 1 Hinge Stop Assembly: Right 05700-003-32-61
1 Hinge Stop Assembly: Left (not shown) 05700-003-32-60
1 Hinge Stop Assembly: Right 05700-003-32-63
1 Hinge Stop Assembly: Left (not shown) 05700-003-32-61
4 1 Cover, Left Hinge Weldment 05700-002-18-41
5 1 Cover, Right Hinge Weldment 05700-002-18-42
Hinge Components secured with: Locknut, 1/4”-20 S/S Hex
with Nylon Insert
05310-374-01-00
6 2 O-Ring 05330-003-32-34
7 1 Latch Spring 05700-003-32-32
8 2 Latch Nut 05700-003-32-33
9 2 Hardware: Locknut, 6-32 S/S Hex with Nylon Insert 05310-373-03-00
2 Screw, 6-32 X 1/4” Flat Head 05305-171-01-00
10 1 Door Switch 05930-003-31-44
11 1 Door Switch Bracket 05700-003-31-43
Door Switch & Bracket Assembly 05700-003-32-21
