48
FRAME AND PANEL COMPONENTS
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Top Shroud Weldment 05700-003-37-06
2 1 Left Shroud Weldment 05700-003-37-04
3 1 Right Shroud Weldment 05700-003-37-05
4 1 Left Frame Weldment 05700-003-31-91
5 1 Swivel Feet 05340-108-02-00
6 1 Right Frame Weldment 05700-003-31-90
4 Hardware: Nut, 1/4”-20 Serrated Hex 05310-959-03-00
4 Nut, 5/16”-18 Cad Spine 05310-959-03-00
7 1 Optional Bottom Panel 05700-003-32-92
8 1 Optional Back Panel 05700-003-33-55
9 1 Standard Back Panel 05700-003-36-35
10 2 Shroud Plug 05700-003-32-50
