7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 525
Description
This command enables the context to allocate resources for CFM bi-directional MIPs in a
VPLS service.
The no form of this command allows the MIPs to retain the Down MEP by de-allocating the
resources.
On the 7210 SAS-R6 and 7210 SAS-R12, the system does not allocate any ETH-CFM
resource slices by default. The user must allocate ETH-CFM resource slices manually. The
default number of resource slices is 0 and a maximum of 1 slice can be allocated.
Parameters num-resources — Specifies the maximum amount of resources for use by ETH-CFM.
Entering a value of def allocates the default number of resource slices.
Values Table 48 lists the parameter values.
Note:
1. Applicable only on SAPs.
bidir-mip-egress
Syntax bidir-mip-egress [num-resources]
no bidir-mip-egress
Context configure>system>resource-profile>egress-internal-tcam>eth-cfm
Supported
Platforms
7210 SAS-R6 (IMMv2 and IMM-c) and 7210 SAS-R12 (IMMv2 and IMM-c)
Description This command allocates resources for the VPLS bi-directional MIP (both ingress and egress
directions) on SAPs only from the egress internal TCAM resource pool.
Note: This command applies only to VPLS SAPs on IMMv2 and IMM-c.
Table 48 Number of Resources Available for ETH-CFM
Platforms Min value Max value Default
7210 SAS-R6 0 1 0
7210 SAS-R12 0 1 0
7210 SAS-R6 and 7210 SAS-R12
IMM-c
1
01 0
