7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 553
Parameters num-resources — Specifies the amount of resources allocated to QoS access port
ingress policies.
Values Table 60 lists the number of resources that can be allocated to QoS
access port ingress policies per 7210 SAS platform.
qos-network-ingress-resource
Syntax qos-network-ingress-resource num-resources
no qos-network-ingress-resource
Context config>system>res-prof>ing-internal-tcam
Supported
Platforms
7210 SAS-R6 and 7210 SAS-R12
Description This command removes resources allocated to port-based and IP interface-based network
ingress QoS policies associated with network and hybrid ports, and makes the resources
available for other features that share the ingress-internal-tcam resource pool (for example,
SAP ingress classification and ingress ACLs).
Table 60 Number of Resources Allocated to QoS Access Port Ingress
Policies on 7210 SAS Platforms
7210 SAS Platform Number of Resources
7210 SAS-Mxp 0 to 4
7210 SAS-R6 IMM-b 0 to 3
7210 SAS-R6 IMM-c 0 to 1
7210 SAS-R12 0 to 3
Note:
• The minimum num-resources configurable is 0 and the maximum num-resources
configurable is 2. The default num-resources is 2 for the default system resource
profile and user-configured system resource profile. A value of 1 is not allowed.
• If the user configures the value 2, one slice is allocated to the network QoS policy IP
interface, and one slice is allocated to the network QoS policy port.
• A reboot is not required after assigning a new value to the qos-network-ingress-
resource command. That is, the value of this command can be changed from 0 to 2 if
there are resources available in the ingress-internal-tcam pool. Similarly, the value can
be changed from 2 to 0 if no network or hybrid ports are configured. If a network port
or hybrid port is configured, changing the value from 2 to 0 is fails and the system
sends an error message.
