System Management Guide Security
Edition: 01 3HE 11018 AAAC TQZZA 173
Begin Time : 2016/09/01 01:01:00 Begin Time (UTC) : 2016/09/01 01:01:00
End Time : Forever End Time (UTC) : Forever
===============================================================================
*A:Sar18 Dut-B#
Table 14 Show Keychain Output Fields
Label Description
Key chain: name
Description The text string description for the keychain
TCP-Option number
send
The TCP option number to be inserted in the header of sent TCP
packets
Admin state The administrative state of the keychain: up or down
TCP-Option number
receive
The TCP option number that will be accepted in the header of
received TCP packets
Oper state The operational state of the keychain: up or down
Used by The protocols associated with this keychain
Expired Indicates whether the keychain has expired
Key entries for key chain: name
Id The ID of the key entry
Direction The stream direction on which keys will be applied for this entry:
send, receive, or send-receive
Algorithm The encryption algorithm to be used by this key entry
Option Indicates the configured IS-IS encoding standard (indicates
“none” if the associated protocol is not IS-IS)
Admin State The administrative state of the key entry: up or down
RX Valid Indicates if the receive key is valid
TX Active Indicates if the transmit (sent) key is active
Tolerance The tolerance time configured for support of both currently active
and new keys
Begin Time The time at which the new key is used to sign and/or authenticate
protocol packets
Begin Time (UTC) The begin time in UTC time
End Time The time at which the key is no longer eligible to authenticate
protocol packets
