Nokia E5-00 User Manual

Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
If you are using a USB charger, connect the charger plug to the USB connector.
3 When the battery is fully charged, disconnect the charger from the device, then
from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use
the device while it is charging. If the battery is completely discharged, it may take
several minutes before the charging indicator appears on the display or before any
calls can be made.
Get started 17

Nokia E5-00 Specifications

General

Display Type	TFT, 256K colors
Display Size	2.36 inches
Resolution	320 x 240 pixels
Operating System	Symbian OS 9.3, Series 60 v3.2 UI
CPU	600 MHz ARM 11
Internal Storage	250 MB
RAM	256 MB
Dimensions	115 x 58.9 x 12.8 mm
Weight	126 g
Announced	2010, April
Status	Discontinued
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
SIM	Mini-SIM
Keyboard	QWERTY
GPU	No
Video	VGA@15fps
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Stand-by	Up to 635 h (2G) / Up to 670 h (3G)
Music play	Up to 38 h
Main Camera	5 MP
Battery	Li-Ion 1200 mAh
3G bands	HSDPA 900 / 2100
Card slot	microSD, up to 32 GB
WLAN	Wi-Fi 802.11 b/g
GPS	Yes, with A-GPS
Colors	Carbon Black, Chalk White, Sky Blue, Copper Brown, Silver Grey
Talk time	Up to 5 h (3G)
