Nokia E5-00 User Manual

Internet access point — Select the internet access point with which to combine
the VPN policy to create secure connections for data transfer.
Proxy server address — Enter the proxy server address of the private network.
Proxy port number — Enter the proxy port number.
Use access point — Select whether connections using this access point are
established automatically.
The settings available for editing may vary.
For the correct settings, contact your company's IT department.
Use a VPN connection in an application
You may have to prove your identity when you log on to the enterprise network.
Contact your company's IT department for the credentials.
To use a VPN connection in an application, the application must be associated with
a VPN access point.
Tip: You can configure the application's connection setting to Always ask, in which
case you select the VPN access point from a list of connections when a connection
is established.
1 In the application in which you want to create a VPN connection, select a VPN
access point as the access point.
2 If you are using legacy authentication, enter your VPN user name and passcode
or password. If the SecurID token has become out of synchronization with the
clock of the ACE/Server, enter the next passcode. If you are using certificate-
based authentication, you may have to enter the key store password.
Settings
Select Menu > Ctrl. panel > Settings.
Settings 185

Nokia E5-00 Specifications

General

Display Type	TFT, 256K colors
Display Size	2.36 inches
Resolution	320 x 240 pixels
Operating System	Symbian OS 9.3, Series 60 v3.2 UI
CPU	600 MHz ARM 11
Internal Storage	250 MB
RAM	256 MB
Dimensions	115 x 58.9 x 12.8 mm
Weight	126 g
Announced	2010, April
Status	Discontinued
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
SIM	Mini-SIM
Keyboard	QWERTY
GPU	No
Video	VGA@15fps
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Stand-by	Up to 635 h (2G) / Up to 670 h (3G)
Music play	Up to 38 h
Main Camera	5 MP
Battery	Li-Ion 1200 mAh
3G bands	HSDPA 900 / 2100
Card slot	microSD, up to 32 GB
WLAN	Wi-Fi 802.11 b/g
GPS	Yes, with A-GPS
Colors	Carbon Black, Chalk White, Sky Blue, Copper Brown, Silver Grey
Talk time	Up to 5 h (3G)
