Nokia E5-00 User Manual

• MMS access point to send and receive multimedia messages
• Internet access point (IAP) to send and receive e-mail and connect to the
internet
Check the type of access point you need with your service provider for the service
you want to access. For availability and subscription to packet data connection
services, contact your service provider.
Network settings
Your device can automatically switch between GSM and 3G networks. The GSM
network is indicated with
in the standby mode. The 3G network is indicated with
.
Select Menu > Ctrl. panel > Settings and Phone > Network and from the
following:
Network mode — Select which network to use. If you select Dual mode, the device
uses the GSM or 3G network automatically, according to the network parameters
and the roaming agreements between the wireless service providers. For details
and roaming costs, contact your network service provider. This option is shown only
if supported by the wireless service provider.
A roaming agreement is an agreement between two or more service providers to
enable the users of one service provider to use the services of other service
providers.
Operator selection — Select Automatic to set the device to search for and select
one of the available networks, or Manual to manually select the network from a
list. If the connection to the manually selected network is lost, the device sounds
an error tone and asks you to reselect a network. The selected network must have
a roaming agreement with your home cellular network.
Cell info display — Set the device to indicate when it is used in a cellular network
based on microcellular network (MCN) technology and to activate cell info reception.
Connectivity 85

Nokia E5-00 Specifications

General

Display Type	TFT, 256K colors
Display Size	2.36 inches
Resolution	320 x 240 pixels
Operating System	Symbian OS 9.3, Series 60 v3.2 UI
CPU	600 MHz ARM 11
Internal Storage	250 MB
RAM	256 MB
Dimensions	115 x 58.9 x 12.8 mm
Weight	126 g
Announced	2010, April
Status	Discontinued
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
SIM	Mini-SIM
Keyboard	QWERTY
GPU	No
Video	VGA@15fps
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Stand-by	Up to 635 h (2G) / Up to 670 h (3G)
Music play	Up to 38 h
Main Camera	5 MP
Battery	Li-Ion 1200 mAh
3G bands	HSDPA 900 / 2100
Card slot	microSD, up to 32 GB
WLAN	Wi-Fi 802.11 b/g
GPS	Yes, with A-GPS
Colors	Carbon Black, Chalk White, Sky Blue, Copper Brown, Silver Grey
Talk time	Up to 5 h (3G)
