NORAM 65ET GRADER
4-39
Lubrication and Maintenance - Grader Components
4
Every 2000 Hours or 1 Year
Tandem Drive Case Oil - Change
Change tandem case oil when oil is warm.
NOTE: On right side tandem case the drain plug is
at the front. On the left side the drain plug is at the
rear. To aid drainage, use a jack to raise end of case
opposite of drain plug.
1. Remove fill plug on top of tandem case.
2. Remove drain plug
(1) from bottom inside of tandem
case. Allow oil to drain into a suitable container.
Dispose of waste fluid according to federal, state and
local laws.
3. Clean area around drain and replace plug.
4. Remove check plug
(2). Fill case using top fill plug
until oil level is even with bottom of check plug.
Repeat for other side.
NOTE: Tandem drive case must be level to check fill
level.
