NORAM 65ET GRADER
2-32
General Information
2
Electronic Display
View Engine Diagnostics 2 Screen
View Engine Diagnostics 2 Screen displays the following:
• Battery
• Manifold Temperature
•Engine Model
•DEF Level
• DEF Temperature
•Hest Lamp
• Inhibit Lamp
•Force Lamp
• SCR Cleaning Lamp
• Regeneration Force Icon
• Regeneration Inhibit Icon
To activate Regeneration Force or Regeneration Inhibit, press the Control Keys associated with the
desired arrows. Press the Control Key associated with the “ESC” icon to return to the Menu Screen.
View Transmission Diagnostics Screen
View Transmission Diagnostics Screen displays the
following:
• Transmission Oil Temperature
• Torque Converter Temperature
• Current Gear
• Input Shaft Speed
• Output Shaft Speed
•Ratio
• Inching
•Brake
• Transmission Torque Monitoring
NOTE: View Transmission Diagnostics Screen is a read only screen. The Up, Down, and Enter
Control Keys do not function in View Transmission Diagnostics Screen.
