Norco MITX-6922 - Page 24

MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset
17
KBMS:
Signal Name
Pin
Signal Name
KB_DATA
1
2
NC
GND
3
4
VCC_KM
KB_CLK
5
6
NC
MS_DATA
7
8
NC
GND
9
10
VCC_KM
MS_CLK
11
12
NC
GND
13
14
GND
GND
15
16
GND
GND
17
2.5.7 Programmable I/O Interface（JGPIO1、JGPIO2）
Provide two 2×10Pin programmable I/O interface.
KBMS
