5
M10 x 19mm Patch
Screw (61)–18
M10 Split
Washer (79)–14
M8 Split
Washer (80)–8
M10 Washer
(64)–4
M6 x 13mm
Patch Screw
(78)–8
M8 x 13mm
Patch Screw
(62)–8
M4 x 30mm
Screw (74)–4
M4 x 16mm
Screw (67)–10
M8 x 25mm Flat
Patch Screw
(68)–6
PART IDENTIFICATION CHART
See the drawings below to identify the small parts needed for assembly. The number in parentheses below each
d
rawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if
it has been preassembled. To avoid damaging parts, do not use power tools for assembly.
