Parts
8-17
E1999 Nordson Corporation
All rights reserved
104 330H
Issued 8/99
Manual 1-8
See Figure 8-6.
Item Part Description Quantity Note
— 247 067 Pump, hydraulic, 25B, 27:1, stainless steel 1 A
1 245 504
SChamber, solvent
1
2 247 069
SGland, packing, 25, 27:1, upper (Type F)
1
3 940 274
SO-ring, Viton, black, 1.312 x 1.438
2
4 247 122
SPlunger, hydraulic, 27:1, stainless steel
1
5 247 072
SSPlunger, hydraulic, 27:1, stainless steel
1
6 503 134
SSCage, ball, pressure
1
7 900 017
SSBall, 440 stainless steel, 0.375, 25
1 B
8 503 382
SSSeat, ball, pressure
1 B
9 247 068
SGland, packing, 25, 27:1, lower (Type F)
1
10 940 304
SSO-ring, Viton, black, 1.625 x 1.750
1
11 940 294
SSO-ring, Viton, black, 1.500 x 1.625
1
12 247 240
SSleeve, high pressure
1
13 983 160
SWasher, lock, split, 0.375, ni pl
8
14 981 402
SScrew, hex head,
3
/
8
-16 x 1
4
15 247 241
SHousing, siphon
1
16 981 408
SScrew, hex head,
3
/
8
-16 x 1
1
/
4
4
17 503 123
SCage, ball, siphon
1
18 244 823
SSeat, ball
1
19 244 824
SSSeat, ball, siphon, 316 stainless steel
1
20 900 018
SSBall, ceramic, 0.500, 25
1
NOTE A:Component of 27:1 stainless steel pump, part 247 062.
B:Included in stainless steel ball and seat kit, part 503 385.
15.27:1 Stainless Steel
Hydraulic Sections
