Notes to service personnel
Be sure to read this manual carefully to gain a thorough understanding of the correct procedures before servicing the
machine.
When some of the mounting screws are used in the angle brackets that secure parts of the machine to the packing materials,
they are meant to be re-used when assembling the machine. All screws that are meant to be re-used in this way are described
in the manual.
Any screws that are not designated for re-use in the manual are not necessary for assembly. There is no need to replace the
screws used in the packing materials mentioned in this manual after you have removed them.
The printer processor may use tapping truss head screws, spike truss head screws and washer head screws.
When attaching the screws once removed, make sure they are on their original positions.
These screws are used for the place where grounding is required.
Tapping truss head screw
Spike truss head screw (green)
Washer head screw (for ground)
SCREW
! It is prohibited to show, provide, lend or transfer this manual to the others except the service personnel.
! The contents of this manual are subject to change without notice.
! Illustrations in this manual may vary depending on the model or manufacturing lot.
