144 Configuring Security using the CLI
Figure 38
Chassis, Insert Trap Receivers dialog box
2
Type the Index, NetAddr, and Community information.
3
Click Insert.
—End—
Graphing SNMP statistics
In the Graph Chassis dialog box, the SNMP tab provides read-only
information about the addresses that the agent software uses to identify
the switch.
To open the SNMP tab, use the following procedure:
Step Action
1
Select the chassis.
2
Choose Graph > Chassis.
The Graph Chassis dialog box appears with the SNMP tab displayed.
3
Click the SNMP tab.
—End—
Nortel Ethernet Routing Switch 2500 Series
Security — Configuration and Management
NN47215-505 (323165-B) 02.01 Standard
4.1 19 November 2007
Copyright © 2007, Nortel Networks
.
