Notifier ACS Series - Page 27

Installation, Configuration, and Programming
PN 15842:K 7/23/2002 27
Annunciator
Key Switch
Connector
Configuration
DIP Switches
Figure 4-3 Reverse View: ACM-16AT, ACM-32A and expanders
Addressing
Switches
EIA-485
Connectors TB2
Power Supply
Connectors TB1
Expander
Connector J1
Tens Ones
Annunciator Address
Annunciator
Key Switch
Connector
DIP Switches
Dip Switch set to
“OFF” position
Dip Switch set to
“ON” position
Figure 4-4 End View: ACM-16AT and ACM-32A
