System 5000 Systems: ACM-16AT and ACM-32A Only
80 PN 15842:K 7/23/2002
S.6 ACS Program Mapping
Annunciator points “track” or follow those system points they are programmed
to annunciate; they do not latch. Table S-1 outlines the annunciation of various
system circuits and functions.
Note: Control Switches marked “not used” will still function as local LAMP
TEST or local ACKNOWLEDGE switches for their respective points.
1. If the Eight-Point Shift (DIP switch #4) is set “ON”, the eight control panel
functions will be shifted from annunciator points 1 through 8 to points 57
through 64 (provided those points exist in the system).
Circuit Type
ACM-16AT & AEM-16AT
ACM-32A &
AEM-32A
Red LED Yellow LED Control Switch
2
IZM-8, IZM-8CS,
IZM-8CS4 circuit
Indicates alarm
status of circuit
6
Indicates trouble status
of circuit
Not used
ICM-4/ICE-4 circuit Indicates Activation
3
Indicates trouble status
of circuit
Controls
Notification Circuit
4
CRM-4/CRE-4 circuit Indicates Activation
3
Indicates trouble status
of relay
Controls Relays
4
TCM-2, TCM-4
VCM-4, DCM-4 circuit
Indicates Activation
3
Indicates trouble status
of relay
Remote Switch
Functions
4
AIM-200 zone
5
Indicates alarm status
of circuit
Indicates trouble status
of circuit
Not used
Annunciator Point #1
1
Indicates
System Alarm
Indicates
System Trouble
ACKNOWLEDGE
Annunciator Point #2 Not used Indicates signals
have been silenced
SIGNAL SILENCE
Annunciator Point #3 Not used Not used SYSTEM RESET
Annunciator Point #4 Not used Indicates
Supervisory condition
Not used
Annunciator Point #5 Indicates that
Notification Circuit 1
has been activated
Indicates trouble status
of circuit
Controls
Notification Circuit #1
Annunciator Point #6 Indicates that
Notification Circuit 2
has been activated
Indicates trouble status
of circuit
Controls
Notification Circuit 2
Annunciator Point #7 Indicates that the
Remote Signalling to
Municipal Tie has been
activated
Indicates trouble status
of circuit
7
Controls Remote
Signalling Municipal Tie
Annunciator Point #8 Indicates that the Alarm
Relay has been
activated
Indicates AC Fail Controls
Alarm Relay
Table S-1 Annunciator Program Mapping with System 5000
