Notifier ACS Series Installation Manual

Installation, Configuration, and Programming
PN 15842:K 7/23/2002 39
Table 4-3 Configuring Speaker Control Mode
1 Switch per Group*
Settings: SW 32-4 off, SW32-3 off, SW32-2 off
Resulting Annunciator Point Mapping:
Single-point annunciation
P1, P2, P3, P4, P5, …, P23, P24.
2 Switches per Group*
Settings: SW 32-4 off, SW 32-3 off, SW 32-2 on
Resulting Annunciator Point Mapping:
2-channel, 4 speakers
3 Switches per Group*
Settings: SW 32-4 off, SW 32-3 on, SW 32-2 off
Resulting Annunciator Point Mapping:
3-channel, 4 speakers:
4 Switches per Group*
Settings: SW 32-4 off, SW 32-3 on, SW 32-2 on
Resulting Annunciator Point Mapping:
4-channel, 4 speakers:
5 Switches per Group*
Settings: SW 32-4 on, SW 32-3 off, SW 32-2 off
Resulting Annunciator Point Mapping:
5-channel, 4 speakers
Note: P6, P12, P18, and P24 are unassigned
6 Switches per Group*
Settings: SW 32-4 on, SW 32-3 off, SW 32-2 on
Resulting Annunciator Point Mapping:
5-channel, 4 speakers
7 Switches per Group*
Settings: SW 32-4 on, SW 32-3 on, SW 32-2 off
Resulting Annunciator Point Mapping:
7-channel, 3 speakers
Note: P16, P20 and P24 are unassigned
8 Switches per Group*
Settings: SW 32-4 on, SW 32-3 on, SW 32-2 on
Resulting Annunciator Point Mapping:
8-channel, 3 speakers
Note: The custom labels in this manual include
labels that can be used with the various Speaker
Control Mode settings.
Spkr
1
Spkr
2
Spkr
3
Spkr
4
Channel 1 P1 P3 P5 P7
Channel 2 P2 P4 P6 P8
Spkr
1
Spkr
2
Spkr
3
Spkr
4
Channel 1 P1 P4 P7 P10
Channel 2 P2 P5 P8 P11
Channel 3 P3 P6 P9 P12
Spkr
1
Spkr
2
Spkr
3
Spkr
4
Channel 1 P1 P5 P9 P13
Channel 2 P2 P6 P10 P14
Channel 3 P3 P7 P11 P15
Channel 4 P4 P8 P12 P16
Spkr
1
Spkr
2
Spkr
3
Spkr
4
Channel 1 P1 P7 P13 P19
Channel 2 P2 P8 P14 P20
Channel 3 P3 P9 P15 P21
Channel 4 P4 P10 P16 P22
Channel 5 P5 P11 P17 P23
Spkr
1
Spkr
2
Spkr
3
Spkr
4
Channel 1 P1 P7 P13 P19
Channel 2 P2 P8 P14 P20
Channel 3 P3 P9 P15 P21
Channel 4 P4 P10 P16 P22
Channel 5 P5 P11 P17 P23
Channel 6 P6 P12 P18 P24
Spkr
1
Spkr
2
Spkr
3
Channel 1 P1 P5 P9
Channel 2 P2 P6 P10
Channel 3 P3 P7 P11
Channel 4 P4 P8 P12
Channel 5 P13 P17 P21
Channel 6 P14 P18 P22
Channel 7 P15 P19 P23
Spkr
1
Spkr
2
Spkr
3
Channel 1 P1 P5 P9
Channel 2 P2 P6 P10
Channel 3 P3 P7 P11
Channel 4 P4 P8 P12
Channel 5 P13 P17 P21
Channel 6 P14 P18 P22
Channel 6 P15 P19 P23
Channel 7 P16 P20 P24
*Note: If adding an expander or expanders, the second unit starts at P25 and goes up, to a maximum of P96.
