12 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Main Menu and Event Counts Screen The Main Menu
DISABLE ACS BOARDS: This soft key allows the operator to disable ACS devices during Walk
Test. Press to toggle between the two choices, YES (disable) and NO (enable). Default: YES
Walk Test Loops Parameters
This screen appears when LOOPS is chosen as a parameter at the Walk Test Menu.
The chosen settings are displayed (BASIC, AUDIBLE in Figure 2.6), and installed loops will
display with a participation field. The up and down arrow keys on the keypad navigate through the
fields. Choose YES for participation, NO for no participation, using the
NEXT SELECTION(+)/PREVIOUS SELECTION(-) keys on the keypad.
If this
parameter is
chosen…
The participating devices/points in Basic
Test will be…
The participating devices/points in
Advanced Test will be…
LOOPS All devices/points on all the FACP SLCs
that are set to participate in Walk Test with
the exception of logic equations, whose
activation is suspended. When an input test
is initiated, only the outputs on the
corresponding loop will activate.
All devices/points on all the FACP SLCs
that are set to participate in Walk Test.
When an input test is initiated, outputs
mapped on all loops will activate.
PANEL The entire panel - all devices/points set to
participate in Walk Test - will participate with
the exception of logic equations, whose
activation is suspended. When an input test
is initiated, only the outputs on the
corresponding loop will activate.
The entire panel - all devices/points set
to participate in Walk Test - will
participate. When an input test is
initiated, outputs mapped on all loops
will activate.
DEVICES Individual detectors, input and output
modules tested one at a time.
Detectors, input and output modules
ZONE For BASIC Walk Test only. When the zone
entered in the parameter field is present in a
device’s first (primary) CBE location, that
device will go into Walk Test when the
parameter zone is put into Walk Test. When
an input test is initiated, outputs mapped to
the corresponding zone on all loops will
activate.
n/a
Table 2.1 Walk Test Parameters
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
WALK TEST
SETTINGS: BASIC, AUDIBLE, LOOPS
L1:NO L2:NO L3:YES
L4:NO L5:NO L6:YES
L7:NO L8:NO L9:YES
L10:NO
START TEST
BACK
Once the START TEST soft key has been pressed and the
test begun, this message changes to ABORT
Figure 2.6 Walk Test Loops Programming Screen
