58 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
PrealarmProgram Point Program
FMM-4-20 Monitor Module Programming
Pressing the 4-20 DEVICE SETUP soft key at the Module Point Programming screen will display
this screen.
Figure 3.43 FMM-4-20 Device Setup Screen
Soft Keys
4MA SCALE VALUE: Enter the 4 mA value.
20MA SCALE VALUE: Enter the 20 mA value.
UNITS: Type in the kind of units. (5 spaces.)
HYSTERESIS: Enter the hysteresis value in decimals as a percentage of the overall 4 to 20 mA range.
Default: 0
THRESHOLD SETUP: Press to continue to the THRESHOLD SETUP screen. (Refer to Figure 3.44
on page 58)
ACCEPT: Press to save entries made on this screen.
Pressing the THRESHOLD SETUP soft key at the Module Point Programming screen will display
this screen.
Figure 3.44 FMM-4-20 Threshold Setup Screen
MODULE POINT PROGRAMMING
L03M150
4MA SCALE VALUE: 0.00
20MA SCALE VALUE: 2000.00
UNITS: PPM
HYSTERESIS: 02.0
% ACCEPT
THRESHOLD SETUP BACK
MODULE POINT PROGRAMMING
L03M150
THRESHOLD NUMBER 1
THRESHOLD VALUE: 500.25 PPM
EVENT FAULT LATCHING
FAULT TYPE: FAULT1 ACCEPT
EVENT TRIGGER: LOWER LEVEL BACK
