Notifier AFP-3030 Installation Manual

7 AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016
System Overview Product Diagram
The keyboard/display assembly is shown in Figure 2.3.
Figure 2.2 AFP-3030 installed in a CAB650
Figure 2.3 AFP-3030 Keypad
NZCAB.wmf
Silence Buzzer Button
System Normal LED
Mute Alarm Devices Button
Alarm Routing Activated
LED
Alarm Routing LEDs
QWERTY Keyboard
Fire LED
Alarm Scroll Button
Fault Scroll Button and LED
Reset Button
Disable Button
keypad-NZ-079.wmf
Alarm Devices Test &
Disable Buttons & LEDs
Program, Status
Supervisory Scroll Button and
LED
Other Scroll Button and LED
Door Holder Disable &
Auxiliary Disable Buttons &
LEDs
Delays On/Off Button
and LED
System Fault LED
Alarm Devices LEDs
Pre Alarm LED
Disable Scroll Button and LED

Notifier AFP-3030 Specifications

General

Brand	Notifier
Model	AFP-3030
Category	Control Panel
Language	English
